Battery Electrode Slitting Machine

SPECIFICATIONS

Name: Planetary ball mill
Model: YXQM-2L(Oil seal mute）
Field of Application: Pharmaceuticals, food, geology, metallurgy, agriculture, glass, ceramics, aviation chemicals, biology, materials, lithium power, electronics, plants, biology and so on.
Feed Material: Medium or low hardness, hard, brittle, fibrous, viscous.
Size Reduction Principle: Crushing, grinding, mixing, homogenization, alloying
Main Disk Structure: Planetary main disk gear invades and reinforces in lubricating oil, noise isolation treatment
Standard: CE
Electrical Description: 100-120V/200-240V AC ,50-60Hz, 1PH (0.75KW)
Material Feed Size: < 5 mm  soil<10 mm
Final Fineness: < 100 nm
Batch Size / Feed Quantity: 4 x 500 ml
Grinding Jar Sizes: 50 ml /100 ml / 250 ml / 500 ml
Vacuum Jar Size: 250 ml /500ml( Stainless steel)
Feed Material Capacity: 160 ml*4
Feed balls Capacity: 160 ml*4
Sun Wheel Speed: 10 – 400 r/min
Ball Mill Jar Speed: 20 – 800 r/min
Total Grinding Speed: 1200 /min
Speed Ratio: 1:2
Material of Grinding Tools: Stainless steel, agate, zirconia, corundum, tungsten carbide, nylon, polyurethane, polytetrafluoroethylene, silicon carbide, etc.
Ball Size: 1 / 2 / 3 / 5 / 8 / 10 / 15 / 20 / 25 / 30 mm
No. of Grinding Stations: 2 or 4
Mode: Vertical planetary
Grinding Mode: Dry/wet
Low Temperature Cooling Treatment: Yes (air cooler added)
Oil Seal Position: The bottom of planetary main disk
Disk Dimensions: 360mm
Oil Seal Capacity: 800ml(fill in before using the planetary ball mill)
Noise: < 60dB(Within 3 metre）
Protection Code: IP60
CN Patent: Safety protection (No.ZL 2015 2 0836150.6）
CN Patent: Oil seal silent  (Patent No.ZL 2014 2 0375569.1）
CN Patent: Frequency control(Patent No.ZL 2016 2 0836150.6）
W x H x D Closed: 30 45/64" x 22 53/64" x 26 49/64" (780 x 580 x 680 mm)
Net Weight: 242.5 lbs (110 kg)
